It’s time to supercharge your home network with the Generation 6 wireless network and our latest addition to the beloved hAP series. hAP ax² has everything you might need in a primary home access point – and more! Forget endless reviews and comparisons – this is the perfect device for 99% of homes.

Wireless signal is now stronger than ever. Here are the two main ingredients of hAP ax’s success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let’s compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!

Some might ask – why do we even need higher wireless speeds? Well, countless use cases have been previously impossible or difficult to pull off. For example, working with large media files over the wireless network – without the need to download and upload everything. Do you really have the time to wait? Grab a hAP ax² and save more time for the essential things in life!

The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.

Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall – without sacrificing the strong signal.

With so many products and features on the market, even an experienced user can become confused. So it’s time for a simple truth for a simple choice: you can’t go wrong with a hAP ax² in most homes.

Specification

Specifications

• Product codeC52iG-5HaxD2HaxD-TC
• Suggested price$99.00
• ArchitectureARM 64bit
• CPUIPQ-6010
• CPU core count4
• CPU nominal frequency864 MHz
• CPU Threads count4
• Switch chip modelIPQ-6010
• RouterOS license4
• Operating SystemRouterOS v7
• Size of RAM1 GB
• Storage size128 MB
• Storage typeNAND
• MTBFApproximately 100'000 hours at 25C
• Tested ambient temperature-40°C to 50°C

Wireless capabilities

• Wireless 2.4 GHz Max data rate574 Mbit/s
• Wireless 2.4 GHz Number of chains2
• Wireless 2.4 GHz standards802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz4
• Wireless 2.4 GHz chip modelQCN-5022
• Wireless 2.4 GHz generationWi-Fi 6
• Wireless 5 GHz Max data rate1200 Mbit/s
• Wireless 5 GHz Number of chains2
• Wireless 5 GHz standards802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz4.5
• Wireless 5 GHz chip modelQCN-5052
• Wireless 5 GHz generationWi-Fi 6
• WiFi speedAX1800

Ethernet

• 10/100/1000 Ethernet ports5
• Number of 1G Ethernet ports with PoE-out1

Powering

• Number of DC inputs2 (DC jack, PoE-IN)
• DC jack input Voltage12-28 V
• Max power consumption27 W
• Max power consumption without attachments12 W
• PoE inPassive PoE
• Cooling typePassive
• PoE in input Voltage18-28 V

PoE-out

• PoE-out portsEther 1
• PoE outPassive PoE
• Low voltage PoE-Out current limit600 mA
• Max total out (A)0.6 A
• Total output current0.6
• Total output power16.8W

Certification & Approvals

• CertificationCE, FCC, IC, EAC, ROHS
• IP20

Other

• CPU temperature monitorYes
• Mode buttonYes

Included parts

hAP case base

K-47 wall mount set

24V 1.2A power supply (straight plug)

Note

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
